MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by RIGOL. Integrating 6 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio of 10 GSa/s, extremely high memory depth of up to 500 Mpts, clear 10.1″ display, excellent waveform capture rate of 600.000 wfms/s, and powerful data analysis functions.
Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional & accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.
In today’s inegrated designfield, a highly integrated comprehensive digital oscilloscope has become a useful tool for design engineers. The MSO7000/DS7000 series digital oscilloscope launched by RIGOL this time integrates 6 independent instruments into 1, including one digital oscilloscope, one 16-channel logic analyzer, one arbitrary waveform generator, one digital voltmeter, one high-precision frequency counter and accumulator, and one protocol analyzer.
The MSO7000/DS7000 series offers you a flexible and economical solution to address your actual needs.
|
Model |
Napięcie |
Prąd |
Moc |
Rozdzielczość |
Dokładność |
Rozmiar |
|
IT8902G-150-200 |
150 V |
200 A |
2 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
4 U |
|
IT8902L-150-200 |
150 V |
200 A |
2 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
4 U |
|
IT8904G-150-400 |
150 V |
400 A |
4 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
4 U |
|
IT8904L-150-400 |
150 V |
400 A |
4 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
4 U |
|
IT8906G-150-600 |
150 V |
600 A |
6 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
4 U |
|
IT8906L-150-600 |
150 V |
600 A |
6 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
4 U |
|
IT8908G-150-800 |
150 V |
800 A |
8 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
8 U |
|
IT8908L-150-800 |
150 V |
800 A |
8 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
8 U |
|
IT8912G-150-1200 |
150 V |
1200 A |
12 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
8 U |
|
IT8912L-150-1200 |
150 V |
1200 A |
12 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
8 U |
|
IT8918G-150-1800 |
150 V |
1800 A |
18 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
15 U |
|
IT8918L-150-1800 |
150 V |
1800 A |
18 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
15 U |
|
IT8924G-150-2400 |
150 V |
2400 A |
24 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
27 U |
|
IT8924L-150-2400 |
150 V |
2400 A |
24 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
27 U |
|
IT8930G-150-2400 |
150 V |
2400 A |
30 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
27 U |
|
IT8930L-150-2400 |
150 V |
2400 A |
30 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.15%FS) |
27 U |
|
IT8936G-150-2400 |
150 V |
2400 A |
36 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
27 U |
|
IT8936L-150-2400 |
150 V |
2400 A |
36 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.15%+0.15%FS) |
27 U |
|
IT8942G-150-2400 |
150 V |
2400 A |
42 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.15%FS) |
37 U |
|
IT8942L-150-2400 |
150 V |
2400 A |
42 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.15%+0.2%FS) |
37 U |
|
IT8948G-150-2400 |
150 V |
2400 A |
48 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.2%FS) |
37 U |
|
IT8948L-150-2400 |
150 V |
2400 A |
48 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.2%+0.2%FS) |
37 U |
|
IT8954G-150-2400 |
150 V |
2400 A |
54 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.15%+0.2%FS) |
37 U |
|
IT8954L-150-2400 |
150 V |
2400 A |
54 kW |
1mV/10mA |
±(0.05%+0.05%FS)/ ±(0.2%+0.25%FS) |
37 U |
|
IT8902G-600-140 |
600 V |
140 A |
2 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
4 U |
|
IT8902L-600-140 |
600 V |
140 A |
2 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
4 U |
|
IT8904G-600-280 |
600 V |
280 A |
4 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
4 U |
|
IT8904L-600-280 |
600 V |
280 A |
4 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
4 U |
|
IT8906G-600-420 |
600 V |
420 A |
6 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
4 U |
|
IT8906L-600-420 |
600 V |
420 A |
6 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.1%+0.1%FS) |
4 U |
|
IT8908G-600-560 |
600 V |
560 A |
8 kW |
1mV/1mA |
±(0.05%+0.05%FS)/ ±(0.05%+0.1%FS) |
8 U |
