Key Features
-
Conforms to international standards for battery testing: IEC, ISO, UL, and GB/T, etc.
-
Regenerative battery energy discharge (Eff. >90%, PF >0.95, I_THD <5%)
-
4 voltage and current ranges for auto ranging function to provide optimum resolution
-
High accuracy current/voltage measurement (±0.05%FS/±0.02%FS)
-
2ms current slew rate and 1ms data acquisition
-
Dynamic (current/power) driving profile simulation tests for NEDC, FUDS, HPPC
-
Test channel parallel function
-
Test data analysis function
-
Data recovery protection (after power failure)
-
Automatic protection for error condition
-
Battery simulator (option)
-
High power testing equipment
– Voltage range : 10~1000V
– Current range : 0~1500A
– Power range : 0~600kW
-
Customized integration functions
– Integrated temperature chamber
– BMS data analysis
– Multi-channel voltage/temperature recording
Fields of application
-
Power battery module
-
Energy storage system
-
Motor driver
-
power control system
